AQUILA ZERO CONDUCTIVITY Overview of the Ro Plant.

Total Dissolved Solids (TDS) is a measure of the combined content of all contaminants contained in drinking water. AQUILA Zero conductivity RO Plants helps to get pure water with Zero Dissolved Solids and Zero TDS.

AQUILA CARES

Aquila also provides after sales support, such as plant operation and maintenance, we identify customer needs based on CapEx and OpEx compatibility, we also supply all types of turnkey projects and their O&M also. At Aquila, design is important and we work tirelessly to find the perfect solutions for our customers through our technological knowhow and ability to give customized solutions. Our design concepts and continual upgradation helps us implement successful solutions. Our need to satisfy our customers is the motivation behind our success.

Aquila RO Plants to provide Zero TDS are available in sizes ranging from 0.25 m3/hr to 100 m3/hr, with a variety of customizable options to suit your needs.

How Does Zero Conductivity RO Plant Work?

Reverse Osmosis Plant is the most well-known RO Plant. Reverse osmosis (RO) removes TDS by pushing water through a synthetic membrane under pressure. Only molecules with a diameter of less than 0.0001 micron can pass through the membrane's minuscule holes. The water molecules are larger than the molecules of dissolved metals and salts, therefore the water will squeeze through the barrier, leaving the metals and salts behind.

A competent Reverse Osmosis system like Aquila Zero Conductivity RO Plant can remove 99 percent of dissolved mineral salts from water. To protect the membrane and eliminate organics, a pre-filter is frequently required.

We design Ro Plants specifically to meet Customer needs, such as Maximum Recovery, Zero TDS, Zero Dissolved Solids, Two Pass, Two/Three Stage, Scada Control, Hmi Display with Op 485 Output, and many more.

It is used in purification and distillation of water, waste material treatment, and a variety of other chemical and biochemical laboratory and industrial operations.

CHOOSE AQUILA RO for ZERO DISSOLVED SOLIDS

Most organic compounds, as well as up to 99 percent of the top soil and ions, are removed by the Aquila Zero Conductivity Ro Plant giving us the purest water.

Aquila Zero Conductivity RO Plant is the best option for you if you are looking for a system that gives you Zero Dissolved Solids in an environmentally friendly way and is easy to install. The Zero Conductivity RO Plant is not only easy to install, but it is also very durable, low maintenance and long lasting.

RO PLANT TECHNICAL & DESIGN FEATURES

Flow :0.2M3/hr to 100M3/hr
Inlet TDS UPTO 42000ppm
PERMETE TDS 90 TO 99% REMOVAL FROM INLET PPM
Flux DESIGN 15 lmh to 30 lmh
Temperature 5-85º C
Type of Membranes BW/SW/LF/HS
SDI < 3 at inlet
Control Panel Type Microprocessor / hmi display with PLC / Scada
Flow Measurement Rota meter / digital flow meters/Flow Transmitter
multi grade filter Reduce Turbidity & Total Suspended Solids
activated carbon filter Remove Colour,odor,toxicity etc.
Micron Cartridge Filters 20 micron & 5 Micron cartridges
High Pressure Pump SS 304 & 316 ALL WETTED PARTS
RO Skid SS/MSEP
PERMETE WATER Micro oraganisms NILL (Require UV IN PRODUCT LINE)
PERMETE WATER PH 7.0 (+/- 0.5)
PERMETE WATER COLOUR NILL
PERMETE WATER ODOR NILL
PERMETE SILICA BELOW LIMIT
RECOVERY 30% TO 95%
O&M WE MAINTAIN PLANT AS PER NEED
Low Pressure Switch To Protect HPP From Dry Run
High Pressure Switch TO CONTROL PRESSURE
Floaty Auto on/off
Dosing System As per DESIGN
differential pressure transmeter Indicate Membrane Cleaning time
online tds meter Measure tds
online ph meter Measure ph
orp meter Measure Oxidation Value
clean in place(cip) system For Maintenance
op 485/ data logger to check all parameters
overload protection RWP & HPP ARE INTERLINK & PROTECTION FROM OVERLOAD

DESIGN

  • AS PER FEED WATER ANALYTICAL PARAMETERS AND CUSTOMER END WATER QUALITY REQUIRENMENT WE DESIGN THE SYSTEM
  • WE DESIGN THE SYSTEM WHICH CAN BE EASY TO OPERATE AND MAINTAIN.
  • USING VARIOUS TECHNOLOGIES WE PROVIDE SUSTAINABLE DESIGN.
  • WE ARE USING DIFFERENT TYPES OF MEMBRANES AND ITS MAKES AND DIFFERENT TYPE OF PUMPS FOR COST EFFECTIVE SOLUTION
  • WE ARE USING ACCURATE PRE & POST RO TREATMENT TO ACHIEVE REQUIRE PARAMETERS.
  • DEEP ANALYSIS , ACCURATE DESIGN , AND SUCCESSFUL O&M
  • WE BELIEVE IN THE CONCEPT CALLED SUCCESS BY DESIGN. THIS MEANS, THATRECURRING SUCCESS CANNOT TAKE PLACE BY CHANCE OR BY ACCIDENT. INSTEAD, IT HAS TO BE CRAFTED,IT HAS TO BE PLANNED.
  • WE ARE SUCCESS IN CLEAN WATER AS WELL AS WASTE WATER DESIGN
  • WE HAVE ACHIEVED 100% RESULTS WHICH WE HAVE COMMITED TO CLIENT.IN CLEAN WATER AND WASTE WATER DESIGN

Silent features

  • CUSTOMIZE programmable controls as per requirement.
  • ALL COMPONENTS USE WITH ITS TEST CERTIFICATE ONLY
  • PLUG AND PLAY ENGINEERED PLANT For Quick Installation
  • Inbuilt Clean-in-place connections For Easy Maintanance.
  • Utilize Minimum footprint but without compromising it's o&m space.
  • provide each project's user manual with Components Data sheet,Test Certificates,Daily Operation And Maintanance Logsheet.
  • Quick Approval Systems Which keeps project moving fast
  • Easy to install and Accurate operation & maintainance.
  • Produces high quality Neutral Water
  • Variety of cost effective standard Components.
