Dialysis Ro Plant Overview

We Design Ro Plant Particularly As Per Customer Requirement Like Maximum Recovery, Zero TDS, Two Pass, Two/Three Stage, Scada control, Hmi Display With Op 485 Output And Many more, Also We Provide After Sales Support Like Operation And Maintenance Of Plants, Also We Identify Customer’s Need As Per Opex And Capex compatibility, We Also Supply All Types Of Turnkey Project And Its O&M Also., Design Is Important In Aquila Because It's An Incredibly Powerful Force, Forever To Get The Perfect Solution. The Value Of Good Design Is The Heightened Chances Of Success. Our Maximum Business Are From Our Customers Only,.., Aquila Ro Plants Are Available From 0.25m3/Hr To 100 M3/Hr With Wide Range Of Customizable Options As Per Requirement.

Reverse Osmosis Working Principal

RO Plant is acknowledged as Reverse Osmosis Plant. It is the manifestation of water flow through a semi penetrable membrane that wedges the transport of salts or other solutes through it. Reverse Osmosis is an essential effect in all organic organizations. It is only applied in the direction for water purification and distillation, waste material treatment, and many other chemical and biochemical laboratory and industrial processes.

RO removes most organic compounds and up to 99% of all top soil and ions. Reverse Osmosis Works By Using A High Pressure Pump To Increase The Pressure Of The Pre-Treated Water And Force The Water Across The Semi-Permeable Ro Membrane, Leaving Almost All (Around 95% To 99%) Of Dissolved Salts Behind In The Reject Stream.

RO PLANT TECHNICAL & DESIGN FEATURES

Flow :0.2M3/hr to 100M3/hr
Inlet TDS UPTO 42000ppm
PERMETE TDS 90 TO 99% REMOVAL FROM INLET PPM
Flux DESIGN 15 lmh to 30 lmh
Temperature 5-85º C
Type of Membranes BW/SW/LF/HS
SDI < 3 at inlet
Control Panel Type Microprocessor / hmi display with PLC / Scada
Flow Measurement Rota meter / digital flow meters/Flow Transmitter
multi grade filter Reduce Turbidity & Total Suspended Solids
activated carbon filter Remove Colour,odor,toxicity etc.
Micron Cartridge Filters 20 micron & 5 Micron cartridges
High Pressure Pump SS 304 & 316 ALL WETTED PARTS
RO Skid SS/MSEP
PERMETE WATER Micro oraganisms NILL (Require UV IN PRODUCT LINE)
PERMETE WATER PH 7.0 (+/- 0.5)
PERMETE WATER COLOUR NILL
PERMETE WATER ODOR NILL
PERMETE SILICA BELOW LIMIT
RECOVERY 30% TO 95%
O&M WE MAINTAIN PLANT AS PER NEED
Low Pressure Switch To Protect HPP From Dry Run
High Pressure Switch TO CONTROL PRESSURE
Floaty Auto on/off
Dosing System As per DESIGN
differential pressure transmeter Indicate Membrane Cleaning time
online tds meter Measure tds
online ph meter Measure ph
orp meter Measure Oxidation Value
clean in place(cip) system For Maintenance
op 485/ data logger to check all parameters
overload protection RWP & HPP ARE INTERLINK & PROTECTION FROM OVERLOAD

DESIGN

  • AS PER FEED WATER ANALYTICAL PARAMETERS AND CUSTOMER END WATER QUALITY REQUIRENMENT WE DESIGN THE SYSTEM
  • WE DESIGN THE SYSTEM WHICH CAN BE EASY TO OPERATE AND MAINTAIN.
  • USING VARIOUS TECHNOLOGIES WE PROVIDE SUSTAINABLE DESIGN.
  • WE ARE USING DIFFERENT TYPES OF MEMBRANES AND ITS MAKES AND DIFFERENT TYPE OF PUMPS FOR COST EFFECTIVE SOLUTION
  • WE ARE USING ACCURATE PRE & POST RO TREATMENT TO ACHIEVE REQUIRE PARAMETERS.
  • DEEP ANALYSIS , ACCURATE DESIGN , AND SUCCESSFUL O&M
  • WE BELIEVE IN THE CONCEPT CALLED SUCCESS BY DESIGN. THIS MEANS, THATRECURRING SUCCESS CANNOT TAKE PLACE BY CHANCE OR BY ACCIDENT. INSTEAD, IT HAS TO BE CRAFTED,IT HAS TO BE PLANNED.
  • WE ARE SUCCESS IN CLEAN WATER AS WELL AS WASTE WATER DESIGN
  • WE HAVE ACHIEVED 100% RESULTS WHICH WE HAVE COMMITED TO CLIENT.IN CLEAN WATER AND WASTE WATER DESIGN

Silent features

  • CUSTOMIZE programmable controls as per requirement.
  • ALL COMPONENTS USE WITH ITS TEST CERTIFICATE ONLY
  • PLUG AND PLAY ENGINEERED PLANT For Quick Installation
  • Inbuilt Clean-in-place connections For Easy Maintanance.
  • Utilize Minimum footprint but without compromising it's o&m space.
  • provide each project's user manual with Components Data sheet,Test Certificates,Daily Operation And Maintanance Logsheet.
  • Quick Approval Systems Which keeps project moving fast
  • Easy to install and Accurate operation & maintainance.
  • Produces high quality Neutral Water
  • Variety of cost effective standard Components.
